Product Description
Gauge Specifications:
22 Gauge / 0.644mm
0.695 Ohms/ft at room temperature
24 Gauge / 0.511mm
1.101 Ohms/ft at room temperature
26 Gauge / 0.405mm
1.760 Ohms/ft at room temperature
28 Gauge / 0.321mm
2.803 Ohms/ft at room temperature
30 Gauge / 0.255mm
4.450 Ohms/ft at room temperature
32 Gauge / 0.202mm
6.953 Ohms/ft at room temperature
34 Gauge / 0.16mm
11.21 Ohms/ft at room temperature
36 Gauge / 0.127mm
18.48 Ohms/ft at room temperature
Wire Specifications:
- Alloy: Stainless Steel 316L
- Shape: Round
- Heat Treatment: Annealed (soft)
- Melting Temperature: 2550°F / 1400°C
- Max Operating Temp: 1700°F / 925°C
